Fenix LD30 Rechargeable Compact LED Flashlight, Black, 1600 Max Lumens

The Fenix LD30 is an extremely powerful compact flashlight that can blast a maximum 1600 lumens, 673 feet (205 meters). At only 4.3” long, the LD30 is the perfect size everyday carry EDC flashlight. Quickly activate the flashlight with its tactical tail switch and then cycle through the lighting modes with the side switch. The LD30 flashlight is powered by one 18650 li-ion battery or two CR123As. Other features include a two-position body clip, battery level indicator, and it is IP68 rated waterproof/dustproof.

Additional Features of the Fenix LD30

• LUMINUS SST40 LED (cool white) with a lifespan of 50,000 hours.
• Powered by a 18650 rechargeable Li-ion battery (included), two CR123A Lithium batteries can be used for emergency.
• 1600 maximum lumens output and 205 meters beam distance.
• High-performance reliable outdoor flashlight with small size and light weight.
• Boot-up battery level indication and low-voltage warning.
• Instant power activation with momentary on tactical tail switch.
• Simple output selection with side switch.
• Intelligent overheat protection against high surface temperature.
• Low-voltage warning reminds when battery replacement needed.
• Ultra-thin optical lens with coating process.
• Reverse polarity protection, to protect from improper battery insertion.
• Intelligent Memory recalls last used output
• Two-way body clip for versatile attachment.
• Made of durable high-strength and oxidation-resistance aluminum.
• Premium type HAIII hard-anodized anti-abrasive finish.

Operating Instructions:

On/off and lock/unlock

Press the tactical tail switch to turn on and lock the flashlight, release it the light will be turned off and unlocked.

Output Selection

With the light switched on, single click the side switch to cycle through Eco→Low→Med→High→Turbo.

Strobe and SOS

With the light switched on, press and hold the side switch for 0.8 seconds to enter strobe, single click the side switch to cycle through Strobe→SOS, press and hold the side switch for 0.8 seconds once again to return back to the previously used output level.

Intelligent Memory Circuit

The light memorizes the last selected output excluding strobe. When turned on again the previously used output will be recalled.

Boot-up Battery Level Indication

Each time the light is turned on, the battery level indicator in the middle of the switch will automatically display the battery status for 3 seconds.

• Green constant on: 100% – 85%, saturated
• Green flashes: 85% – 50%, sufficient
• Red constant on: 50% – 25%, poor
• Red flashes: 25% – 1%, critical

Note: This only works with Fenix ARB-L18 Series 18650 rechargeable Li-ion battery.

LD30 Battery Specifications

Fenix ARB-L18-3400U 18650 rechargeable Li-ion battery is recommended for maintaining perfect lighting performance.
Warning: Do not mix batteries of different brands, sizes, capacities or types. Doing so may cause damage to the flashlight or the batteries being used.

*18650 /16340 Li-ion batteries are powerful cells designed for commercial applications and must be treated with caution and handled with care. Only use quality batteries with circuit protection will reduce the potential for combustion or explosion; but cell damage or short circuiting are potential risks the user assumes.

Battery Replacement

Unscrew the light body and insert the battery with the anode side (+) towards the light head, then screw the light body back on.

LD30 Low-voltage Warning

When the voltage level drops below the preset level, the flashlight is programmed to downshift to a lower brightness level until Eco output is reached. When this happens in Eco output mode, the battery level indicator blinks red to remind you to recharge the battery. To ensure normal use, the flashlight will not turn off automatically and will work till the battery level runs out.
Note: This only works with Fenix 18650 Li-ion battery.

Intelligent Downshift

Time-limited Downshift
After 5 minutes of maintenance, the brightness of the flashlight decreases by about 30 lumens every 6 seconds, and until to about 1200 lumens.

Overheat Protection

1. With the light switched on High output level, and the temperature is detected ≥55°C. The brightness of the flashlight decreases by about 30 lumens every 6 seconds, and until to about 400 lumens. If the temperature is detected <55°C, the brightness of the flashlight increases by about 30 lumens every 6 seconds, and until to about 800 lumens. After the brightness downshifting, High output can be reselected.
2. With the light switched on Turbo output level, and the temperature is detected ≥55°C. The brightness of the flashlight decreases by about 30 lumens every 6 seconds, and until to about 400 lumens. If the temperature is detected <55°C, the brightness of the flashlight increases by about 30 lumens every 6 seconds, and until to about 1200 lumens. If the temperature exceeds 55°C in the first 5 minutes, the brightness will drop directly to 800 lumens. After the brightness downshifting, Turbo output can be reselected.

Voltage Downshift

When the voltage level drops below 3V, the flashlight is programmed to downshift to a lower brightness level until Eco output is reached. (After the downshifting, other output levels can be selected by single clicking the side switch, but if the battery voltage is still detected below 3V, the downshifting will begin after 1 second).

Usage and Maintenance of the Fenix LD30

• Disassembling the sealed head can cause damage to the light and will void the warranty.
• Fenix recommends using an excellent quality battery.
• If the light will not be used for an extended period, remove the battery, or the light could be damaged by electrolyte leakage or battery explosion.
• Unscrew the tail cap half a turn or take out the battery to prevent accidental activation during storage or transportation. Recharge a stored battery every four months to maintain optimal battery performance.
• Long-term use can result in O-ring wear. To maintain a proper water seal, replace the ring with an approved spare．
• Periodic cleaning of the battery contacts improves the lamp’s performance as dirty contacts may cause the lamp to flicker, shine intermittently, or even fail to illuminate for the following reasons:
  A: The battery needs replacing.
  Solution: Replace battery (ensure battery is inserted according to the manufacturer’s specifications).
  B: The threads, PCB board contact or other contacts are dirty.
  Solution: Clean the contact points with a cotton swab soaked in rubbing alcohol.

If the above methods don’t work, please contact your authorized distributor.

Warning

This flashlight is a high-intensity lighting device capable of causing eye damage to the user or others. Avoid shining the flashlight directly into anyone’s eyes.
